Install Package - Mitsubishi Heavy (MHI) Bronte WiFi DXK33ZRA-WF1 9.5kW Wall Split Air Conditioning Package

DXK33ZRA-WF1/DXC33ZRA-W MHI Wall Split Supply & Install




$4,479.00 Incl GST
$4,071.82 Excl GST
In Stock

Supply & Installation Package - Mitsubishi Heavy Industries Bronte Series DXK33ZRA-WF1-SET 9.5kW Wall Split System (Built-In Wi-Fi)

Ideal for a large living or dining room or sitting room, the Bronte® split system features advanced fan blade technology that delivers an impressive long reach airflow of over 18+ meters in cooling mode. This exceptional airflow is available in our 7.1-9.5kW models, ideal for those larger spaces. The new WF1 range provides the convenience of being able to control your Bronte® Air Conditioner from virtually anywhere, with built-in Wi-Fi, plus voice control compatibility via Google or Alexa device, and the NOVAShield™ PM2.5 filter for enhanced air quality.

Standard Installation Inclusions:

  • Wall Split Air Conditioner Installation
  • Suitable for a single-story (lowset) home
  • Back-to-back installation with a maximum 3m pipe run
  • Outdoor unit mounted on the ground

Terms & Conditions:

  • The quoted price represents “Pricing From” based on a standard installation.
  • Non-standard installations may incur additional costs and require a separate quote based on individual site requirements.
  • Pricing does not cover new builds or replacement installations.
  • Brisbane pricing applies to the Brisbane region.
  • Sydney pricing applies to areas within 20km of our Prestons office.
  • For other areas, a custom quote will be provided.

For a tailored quote based on your specific installation needs, contact our Sales Team today!

Features:

  • Advanced jet air technology delivering long reach airflow
  • Allergen clear system to capture and eliminate allergens
  • Wide range of convenient timer functions
  • Energy efficient R32 refrigerant
  • New WF1 range: Built-in Wi-Fi, NOVAShield™ PM2.5 Filter, and Voice Control Compatibility (via Google or Alexa device, sold separately

(DXK33ZRA-WF1-Set-INSTALL)

System Name  DXK21ZRA-WF1-SET  DXK24ZRA-WF1-SET  DXK28ZRA-WF1-SET  DXK33ZRA-WF1-SET  SRK100AVNAWZRF  SRK100AVSAWZRF
Indoor Unit  DXK21ZRA-WF1  DXK24ZRA-WF1  DXK28ZRA-WF1  DXK33ZRA-WF1  SRK100ZR-WF  SRK100ZR-WF
Outdoor Unit  DXC21ZRA-W  DXC24ZRA-W  DXC28ZRA-W  DXC33ZRA-W  FDCA100VNA-W  FDCA100VSA-W
Power Supply  1 Phase, 240V, 50Hz  3 Phase, 380 ~ 415V, 50Hz
Cooling Capacity (kW)  6.3  7.1  8.0  9.5  10.0  10.0
Heating Capacity (kW)  7.1  8.0  9.0  10.3  11.2  11.2
EER/COP  3.99 / 4.44  3.86 / 3.96  3.60 / 3.75  3.71 / 3.90  3.13 / 3.68  3.13 / 3.68
Outdoor Sound Power dB(A)  64  65  68  69
Refrigerant Type/Amount (kg)  R32 / 1.25  R32 / 1.6  R32 / 2.0  R32 / 3.3
Max Pipe Length (m)  30  50
Max Level Difference (m)  I.D.U Higher 20 / O.D.U Higher 20  I.D.U Higher 15 / O.D.U Higher 50
Indoor Dimensions (HxWxD) (mm)  339 x 1197 x 262
Outdoor Dimensions (HxWxD) (mm)  640 x 800(+71) x 290  750 x 880(+88) x 340  845 x 970(+89) x 370
Indoor Weight (kg)  15.5  16.5
Outdoor Weight (kg)  45  58  70.5  77  78
Pipe Sizes (mm) (Liquid/Gas)  6.35 / 12.7  6.35 / 15.88  9.52 / 15.88
SKU DXK33ZRA-WF1-Set-INSTALL
Brand Mitsubishi Heavy Industries (MHI)
Shipping Weight 85.5000kg
Shipping Cubic 0.437411000m3
Unit Of Measure ea

Warranty

  • Mitsubishi Heavy Industries offers up to a 5-year parts and labour warranty for all of their Air Conditioners. Note your product might not be eligible for the full 5-year warranty. Refer to their terms and conditions.

  • Lawson Air Conditioning offers a 1-year warranty on all Split System Installs.
