Install Package - Mitsubishi Electric MSZLN25VG2RKIT3 2.5kW Wall Split Air Conditioning Package

MSZLN25VG2RKIT3 Wall Split Supply & Install (Red)




$2,630.00 Incl GST
$2,390.91 Excl GST
In Stock

Supply & Installation Package - Mitsubishi Electric MSZLN25VG2RKIT3 2.5kW Wall Split System (Red) (Built-In Wi-Fi)

The LN Series is a wall mounted system that blends energy efficiency with a sleek and ultra modern design. The stylish design is available with a range of deep, rich colours like pearl white, ruby red and onyx black, resulting in a premium quality feel.

Standard Installation Inclusions:

  • Wall Split Air Conditioner Installation
  • Suitable for a single-story (lowset) home
  • Back-to-back installation with a maximum 3m pipe run
  • Outdoor unit mounted on the ground

Terms & Conditions:

  • The quoted price represents “Pricing From” based on a standard installation.
  • Non-standard installations may incur additional costs and require a separate quote based on individual site requirements.
  • Pricing does not cover new builds or replacement installations.
  • Brisbane pricing applies to the Brisbane region.
  • Sydney pricing applies to areas within 20km of our Prestons office.
  • For other areas, a custom quote will be provided.

For a tailored quote based on your specific installation needs, contact our Sales Team today!

Features:

  • 3D i-See Sensor
  • Absence Detection
  • Built In Wi-Fi Control
  • Direct/Indirect Airflow
  • Dual Barrier Coating
  • Dual split vane technology
  • Plasma Quad Plus Filter
  • Sleek and ultra modern design

(MSZLN25VG2RKIT3-INSTALL)

System Name MSZLN25VG2(V/B/R)KIT3 MSZLN35VG2(V/B/R)KIT3 MSZLN50VG3(V/B/R)KIT3 MSZLN60VG3(V/B/R)KIT3
Indoor Unit MSZ-LN25VG2(V/B/R)-A3 MSZ-LN35VG2(V/B/R)-A3 MSZ-LN50VG3(V/B/R)-A1 MSZ-LN60VG3(V/B/R)-A1
Outdoor Unit MUZ-LN25VG2-A2 MUZ-LN35VG2-A2 MUZ-LN50VG3-A1 MUZ-LN60VG2-A1
Power Supply 1 Phase, 220 ~ 240V, 50Hz
Refrigerant R32
Cooling Capacity (kW) 2.5 3.5 5.0 6.1
Heating Capacity (kW) 3.2 4.0 6.0 6.8
Capacity Min-Max Cool/Heat (kW) 1.0-3.5 / 0.7-5.4 0.8-4.0 / 0.9-6.3 1.0-6.0 / 1.0-8.2 1.4-6.9 / 1.8-9.8
Total Rated Input Cool/Heat (kW) 0.49 / 0.60 0.82 / 0.82 1.38 / 1.48 1.73 / 1.80
Total Input Min-Max Cool/Heat (kW) 0.18-0.90 / 0.15-1.50 0.16-1.18 / 0.17-1.88 0.19-2.33 / 0.17-3.00 0.27-2.73 / 0.33-3.62
EER/COP 5.1 / 5.33 4.27 / 4.88 3.62 / 4.05 3.53 / 3.78
AEER/ACOP 5.07 / 5.30 4.25 / 4.86 3.61 / 4.04 3.52 / 3.77
TCSPF Residential (H/Avg/C) - Cool 6.92 / 6.48 / 6.74 6.08 / 5.75 / 6.05 5.32 / 5.07 / 5.38 4.85 / 4.64 / 4.87
HSPF Residential (H/Avg/C) - Heat 5.54 / 5.25 / 4.93 5.42 / 5.03 / 4.62 4.75 / 4.32 / 3.87 4.72 / 4.21 / 3.74
ZERL Residential Star Rating (H/Avg/C) - Cool 5.0 / 4.5 / 5.0 4.5 / 4.0 / 4.5 3.5 / 3.5 / 3.5 3.0 / 3.0 / 3.0
ZERL Residential Star Rating (H/Avg/C) - Heat 4.0 / 3.5 / 3.0 3.5 / 3.5 / 3.0 3.0 / 2.5 / 2.0
Rated Running Current Cool/Heat (A) 2.7 / 3.4 3.8 / 3.8 6.3 / 6.8 7.8 / 7.53
Sound Pressure Level (Q/L/M/H/SH) dBA - Cool 19 / 23 / 29 / 36 / 42 19 / 24 / 29 / 36 / 43 27 / 31 / 35 / 39 / 46 29 / 37 / 41 / 45 / 49
Sound Pressure Level (Q/L/M/H/SH) dBA - Heat 19 / 24 / 29 / 38 / 45 19 / 24 / 29 / 38 / 45 25 / 29 / 35 / 43 / 47 29 / 37 / 41 / 45 / 49
Sound Pressure Level Out (PWL) dBA - Cool 46(60) 49(61) 51(64) 55(65)
Sound Pressure Level Out (PWL) dBA - Heat 49(61) 50(62) 54(66) 55(69)
Air Volume In Cool/Heat (Quiet-SHi) L/s 78-207 / 75-232 78-217 / 75-232 95-232 / 90-262 118-262 / 108-262
Max. Running Current (A) 7.1 9.9 13.9 15.2
Indoor Dimensions (HxWxD) (mm) 307 x 890 x 233
Outdoor Dimensions (HxWxD) (mm) 550 x 800 x 285 714 x 800 x 285 880 x 840 x 330
Indoor Weight (kg) 15.5 16
Outdoor Weight (kg) 33 34 40 53
Pipe Sizes (mm) (Liquid/Gas) 6.35 / 9.52 6.35 / 12.7
Max Piping Length/Height (m) 20 / 12 30 / 12 30 / 15
Outdoor Operating Range Cool/Heat (C) -10 to 46 / -15 to 24
Refrigerant Amount Pre-Charged (kg) 0.80 0.85 1.25 1.45
SKU MSZLN25VG2RKIT3-INSTALL
Brand Mitsubishi Electric
Shipping Weight 48.5000kg
Unit Of Measure ea

Warranty

Lawson Air Conditioning offers a 1-year warranty on all Split System Installs.
