Fujitsu SET-ABTH24KRTA-YH 7.1kW Under Ceiling R32 Single Phase Air Conditioning System (Wireless Controller)

Fujitsu-SET-ABTH24KRTA-YH
Fujitsu-SET-ABTH24KRTA-YH
Fujitsu-SET-ABTH24KRTA-YH

Fujitsu SET-ABTH24KRTA-YH 7.1kW Under Ceiling R32 Single Phase Air Conditioning System (Wireless Controller)

ABTH24KRTA / AOTH24KBTA Under Ceiling AC




$3,377.00 Incl GST
$3,070.00 Excl GST
In Stock
Control Option

Calculate Shipping


Request Separate Shipping Quote
Best suited for large or bulky orders. After receiving your order, our team will contact you to arrange a custom shipping quote based on current freight market rates to your location. We work with multiple freight providers to find the best pricing and delivery option for your needs. Please note that final shipping costs will vary from the online shipping estimate.
Pick Up- $0.00 (ETA: 1 days)
Pick Up from our Brisbane Warehouse. Mon - Fri 8am - 4pm. Please wait for pickup confirmation call or email. Or contact us prior to picking up to ensure your unit is packed and ready to go.
Pick Up- $0.00 (ETA: 1 days)
Pick Up from our Sydney Warehouse. Mon - Fri 8am - 4pm. Please wait for pickup confirmation call or email. Or contact us prior to picking up to ensure your unit is packed and ready to go.

System SET-ABTH18KRTA SET-ABTH24KRTA SET-ABTH30KRTA SET-ABTH36KRTA SET-ABTH45KRTA SET-ABTH54KRTA
Indoor Unit ABTH18KRTA ABTH24KRTA ABTH30KRTA ABTH36KRTA ABTH45KRTA ABTH54KRTA
Outdoor Unit AOTH18KBTA AOTH24KBTA AOTH30KBTA AOTH36KBTA AOTH45KBTA AOTH54KBTA
Cooling Capacity Rated/Min-Max kW 5.0 (0.9-5.9) 7.1 (1.8-8.1) 8.5 (2.8-10.3) 10.0 (2.8-11.4) 12.5 (4.0-14.0) 13.0 (4.5-15.0)
Heating Capacity Rated/Min-Max 6.0 (0.9-7.5) 8.0 (2.0-9.1) 10.0 (2.7-11.3) 11.2 (2.7-14.0) 14.0 (4.2-16.5) 15.5 (4.7-18.0)
Power Supply 230V / 1 Phase / 50Hz
EER/COP 3.55 / 3.75 3.13 / 3.81 3.31 / 3.7 3.22 / 3.75 3.02 / 3.70 3.02 / 3.61
Input Power Rated (Max) Cool kW 1.41 (1.95) 2.27 (3.15) 2.57 (4.07) 3.11 (4.11) 4.14 (4.90) 1.51 (1.82)
Input Power Rated (Max) Heat 1.6 (2.39) 2.1 (2.59) 2.7 (4.39) 2.99 (4.35) 3.78 (4.90) 1.66 (2.35)
Star Rating Cooling Hot/Avg/Cold 3.5 / 3.0 / 3.0 3.0 / 3.0 / 3.0 3.0 / 2.5 / 3.0 3.0 / 3.0 / 3.0 3.0 / 2.5 / 3.0 2.5 / 2.5 / 2.5
Star Rating Heating Hot/Avg/Cold 3.0 / 2.5 / 2.0 3.5 / 2.5 / 2.0 3.0 / 2.5 / 2.0 3.5 / 2.5 / 1.5 2.5 / 2.0 / 1.5
TCSPF Residential Hot/Avg/Cold 5.02 / 4.68 / 4.89 4.80 / 4.52 / 4.82 4.62 / 4.40 / 4.63 4.82 / 4.59 / 4.90 4.56 / 4.36 / 4.66 4.48 / 4.08 / 4.16
TCSPF Commercial Hot/Avg/Cold 5.40 / 5.54 / 5.95 5.20 / 5.42 / 5.89 4.94 / 5.09 / 5.47 5.19 / 5.41 / 5.86 4.91 / 5.13 / 5.57 4.81 / 4.83 / 5.12
HSPF Residential Hot/Avg/Cold 4.90 / 4.25 / 3.62 5.22 / 4.42 / 3.71 4.92 / 4.19 / 3.51 5.02 / 4.13 / 3.40 4.89 / 4.15 / 3.47 4.44 / 3.90 / 3.36
HSPF Commercial Hot/Avg/Cold 4.91 / 4.52 / 3.97 5.24 / 4.75 / 4.13 4.93 / 4.49 / 3.90 5.03 / 4.51 / 3.73 4.90 / 4.48 / 3.87 4.44 / 4.12 / 3.65
Running Current Cool/Heat A 6.2 / 7.1 10.0 / 9.2 11.3 / 11.9 13.7 / 13.2 18.1 / 16.8 6.4 / 7.0
Moisture Removal l/hr 2.3 3.1 5.2 2.0
Indoor Sound Pressure Cool Hi/Qu dBA 38 / 31 41 / 29 45 / 32 44 / 32 45 / 34 44 / 32
Indoor Sound Pressure Hea Hi/Qu 38 / 31 41 / 29 45 / 32 44 / 32 45 / 34 44 / 32
Outdoor Sound Pressure Cool/Heat 48 / 49 48 / 50 51 / 53 53 / 53 55 / 57 55 / 56
Outdoor Sound Power 62 68 69 70 71
Indoor Air Circulation Cool/Heat l/sec 233 / 233 342 / 342 389 / 389 514 / 500 528 / 514 583 / 583
Indoor Unit Dimensions HxWxD mm 235 x 1080 x 705 235 x 1390 x 705 235 x 1700 x 705
Outdoor Unit Dimensions HxWxD 632 x 799 x 290 716 x 820 x 315 788 x 940 x 320 998 x 940 x 320
Indoor Unit Weight kg 24 31 38
Outdoor Unit Weight 36 42 52 67
Piping Connects (Liquid/gas) mm 6.35 / 12.7 9.52 / 15.88
Pipe Length Max(Pre-Charged) m 30 (20) 50 (30)
Max Height Difference 20 25 30 20
Operation Range Cool/Heat C -10 to 50 / -15 to 24 -10 to 46 / -15 to 24
Refrigerant Type/Amount kg R32 / 1020 R32 / 1250 R32 / 1900 R32 / 2700

(SET-ABTH24KRTA)

System SET-ABTH18KRTA SET-ABTH24KRTA SET-ABTH30KRTA SET-ABTH36KRTA SET-ABTH45KRTA SET-ABTH54KRTA
Indoor Unit ABTH18KRTA ABTH24KRTA ABTH30KRTA ABTH36KRTA ABTH45KRTA ABTH54KRTA
Outdoor Unit AOTH18KBTA AOTH24KBTA AOTH30KBTA AOTH36KBTA AOTH45KBTA AOTH54KBTA
Cooling Capacity Rated/Min-Max kW 5.0 (0.9-5.9) 7.1 (1.8-8.1) 8.5 (2.8-10.3) 10.0 (2.8-11.4) 12.5 (4.0-14.0) 13.0 (4.5-15.0)
Heating Capacity Rated/Min-Max 6.0 (0.9-7.5) 8.0 (2.0-9.1) 10.0 (2.7-11.3) 11.2 (2.7-14.0) 14.0 (4.2-16.5) 15.5 (4.7-18.0)
Power Supply 230V / 1 Phase / 50Hz
EER/COP 3.55 / 3.75 3.13 / 3.81 3.31 / 3.7 3.22 / 3.75 3.02 / 3.70 3.02 / 3.61
Input Power Rated (Max) Cool kW 1.41 (1.95) 2.27 (3.15) 2.57 (4.07) 3.11 (4.11) 4.14 (4.90) 1.51 (1.82)
Input Power Rated (Max) Heat 1.6 (2.39) 2.1 (2.59) 2.7 (4.39) 2.99 (4.35) 3.78 (4.90) 1.66 (2.35)
Star Rating Cooling Hot/Avg/Cold 3.5 / 3.0 / 3.0 3.0 / 3.0 / 3.0 3.0 / 2.5 / 3.0 3.0 / 3.0 / 3.0 3.0 / 2.5 / 3.0 2.5 / 2.5 / 2.5
Star Rating Heating Hot/Avg/Cold 3.0 / 2.5 / 2.0 3.5 / 2.5 / 2.0 3.0 / 2.5 / 2.0 3.5 / 2.5 / 1.5 2.5 / 2.0 / 1.5
TCSPF Residential Hot/Avg/Cold 5.02 / 4.68 / 4.89 4.80 / 4.52 / 4.82 4.62 / 4.40 / 4.63 4.82 / 4.59 / 4.90 4.56 / 4.36 / 4.66 4.48 / 4.08 / 4.16
TCSPF Commercial Hot/Avg/Cold 5.40 / 5.54 / 5.95 5.20 / 5.42 / 5.89 4.94 / 5.09 / 5.47 5.19 / 5.41 / 5.86 4.91 / 5.13 / 5.57 4.81 / 4.83 / 5.12
HSPF Residential Hot/Avg/Cold 4.90 / 4.25 / 3.62 5.22 / 4.42 / 3.71 4.92 / 4.19 / 3.51 5.02 / 4.13 / 3.40 4.89 / 4.15 / 3.47 4.44 / 3.90 / 3.36
HSPF Commercial Hot/Avg/Cold 4.91 / 4.52 / 3.97 5.24 / 4.75 / 4.13 4.93 / 4.49 / 3.90 5.03 / 4.51 / 3.73 4.90 / 4.48 / 3.87 4.44 / 4.12 / 3.65
Running Current Cool/Heat A 6.2 / 7.1 10.0 / 9.2 11.3 / 11.9 13.7 / 13.2 18.1 / 16.8 6.4 / 7.0
Moisture Removal l/hr 2.3 3.1 5.2 2.0
Indoor Sound Pressure Cool Hi/Qu dBA 38 / 31 41 / 29 45 / 32 44 / 32 45 / 34 44 / 32
Indoor Sound Pressure Hea Hi/Qu 38 / 31 41 / 29 45 / 32 44 / 32 45 / 34 44 / 32
Outdoor Sound Pressure Cool/Heat 48 / 49 48 / 50 51 / 53 53 / 53 55 / 57 55 / 56
Outdoor Sound Power 62 68 69 70 71
Indoor Air Circulation Cool/Heat l/sec 233 / 233 342 / 342 389 / 389 514 / 500 528 / 514 583 / 583
Indoor Unit Dimensions HxWxD mm 235 x 1080 x 705 235 x 1390 x 705 235 x 1700 x 705
Outdoor Unit Dimensions HxWxD 632 x 799 x 290 716 x 820 x 315 788 x 940 x 320 998 x 940 x 320
Indoor Unit Weight kg 24 31 38
Outdoor Unit Weight 36 42 52 67
Piping Connects (Liquid/gas) mm 6.35 / 12.7 9.52 / 15.88
Pipe Length Max(Pre-Charged) m 30 (20) 50 (30)
Max Height Difference 20 25 30 20
Operation Range Cool/Heat C -10 to 50 / -15 to 24 -10 to 46 / -15 to 24
Refrigerant Type/Amount kg R32 / 1020 R32 / 1250 R32 / 1900 R32 / 2700
SKU SET-ABTH24KRTA
Brand Fujitsu
Shipping Weight 73.0000kg
Shipping Cubic 0.415231000m3
Unit Of Measure ea
