Best Prices Daikin FTXC50A-AV 5.0kW Room Air Conditioner Low Cost Installation Brisbane Sydney

Daikin SkyAir FTXC50A-AV 5.0kW Wall Split 1 Phase Air Conditioning System

Calculate Shipping

Request Separate Shipping Quote
Best suited for large or bulky orders. After receiving your order, our team will contact you to arrange a custom shipping quote based on current freight market rates to your location. We work with multiple freight providers to find the best pricing and delivery option for your needs. Please note that final shipping costs will vary from the online shipping estimate.

Pick Up- $0.00 (ETA: 1 days)
Pick Up from our Brisbane Warehouse. Mon - Fri 8am - 4pm. Please wait for pickup confirmation call or email. Or contact us prior to picking up to ensure your unit is packed and ready to go.

Pick Up- $0.00 (ETA: 1 days)
Pick Up from our Sydney Warehouse. Mon - Fri 8am - 4pm. Please wait for pickup confirmation call or email. Or contact us prior to picking up to ensure your unit is packed and ready to go.

System Names	FTXC50A-AV	FTXC60A-AV	FTXC71A-AV	FTXC85A-AV	FTXC100A-AV
Indoor Unit	FTXC50AV1A	FTXC60AV1A	FTXC71AV1A	FTXC85AV1A	FTXC100AV1A
Outdoor Unit	RXC50AV1A	RXC60AV1A	RXC71AV1A	RXC85AV1A	RXC100AV1A
Cooling Capacity Rated/Min-Max (kW)	5.0 (1.4-6.0)	6.0 (1.4-7.1)	7.1 (3.2-8.0)	8.5 (4.0-10.0)	10.0 (5.0-11.2)
Heating Capacity Rated/Min-Max(kW)	6.0 (1.4-7.1)	7.1 (1.4-8.0)	8.0 (3.5-9.0)	10.0 (4.1-11.2)	11.2 (5.1-12.5)
Power Supply	1 Phase, 220-240V, 50Hz
Power Consumption (Cool/Heat) (kW)	1.45 / 1.61	1.80 / 2.05	2.22 / 2.37	2.59 / 3.01	3.11 / 3.48
EER / COP (kW/kW)	3.45 / 3.73	3.33 / 3.46	3.20 / 3.38	3.28 / 3.32	3.22 / 3.22
AEER / ACOP	3.33 / 3.61	3.24 / 3.38	3.13 / 3.31	3.22 / 3.27	3.16 / 3.17
TCSPF Cooling Commercial Hot/Avg/Cold	5.30 / 5.23 / 5.53	5.01 / 4.98 / 5.27	4.85 / 4.88 / 5.19	5.01 / 5.06 / 5.40	5.03 / 5.12 / 5.48
TCSPF Cooling Residential Hot/Avg/Cold	4.80 / 3.99 / 4.00	4.58 / 3.92 / 3.95	4.46 / 3.92 / 4.00	4.61 / 4.10 / 4.21	4.63 / 4.17 / 4.31
HSPF Heating Commercial Hot/Avg/Cold	5.39 / 4.96 / 4.50	5.16 / 4.71 / 4.22	4.47 / 4.16 / 3.79	4.49 / 4.17 / 3.77	4.66 / 4.25 / 3.77
HSPF Heating Residential Hot/Avg/Cold	5.36 / 4.64 / 4.14	5.13 / 4.38 / 3.84	4.46 / 3.94 / 3.52	4.48 / 3.93 / 3.49	4.64 / 3.95 / 3.42
Indoor Decoration Panel Colour	Fresh White
Indoor Airflow Rate (H/M/L) (l/s)	300 / 267 / 233			433 / 383 / 317
Indoor Sound Pressure Level (H/M/L) (dBA)	45 / 42 / 40			49 / 45 / 41
Indoor Sound Power Level (H/M/L) (dBA)	61 / 58 / 56			65 / 62 / 58
Outdoor Unit Colour	Ivory White
Compressor Type	Hermatically Sealed Swing Type
Compressor Motor Output (kW)	1.3		2.4	3.3
R32 Refrigerant Amount/Charge (kg)	0.73 (Charged for 10m)		1.50 (Charged for 10m)
Outdoor Sound Pressure Level Cool/Heat (dBA)	48 / 51		48 / 50	52 / 53	51 / 53
Outdoor Sound Pressure Level Night Quiet Mode (dBA)	44			48	47
Outdoor Sound Power Level (dBA)	68		67	71	70
Indoor Operating Range Cool/Heat (C)	14 to 25 / 15 to 27
Outdoor Operating Range Cool/Heat (C)	-5 to 50 / -15 to 15.5
Pipe Sizes (Liquid/Gas) (mm)	6.4 / 12.7		9.5 / 15.9
Max. Interunit Piping Length (m)	50 (Equivalent Length 70)		75 (Equivalent Length 90)
Max. Installation Height Difference (m)	30
Heat Insulation	Both Liquid and Gas Piping
Indoor Unit Dimensions (HxWxD) (mm)	290 x 1050 x 238			340 x 1200 x 240
Outdoor Unit Dimension (HxWxD) (mm)	595 x 845 x 300		990 x 940 x 320		1430 x 940 x 320
Indoor Unit Weight (kg)	13			17
Outdoor Unit Weight (kg)	45		69	78	93

(FTXC50A-AV)

System Names	FTXC50A-AV	FTXC60A-AV	FTXC71A-AV	FTXC85A-AV	FTXC100A-AV
Indoor Unit	FTXC50AV1A	FTXC60AV1A	FTXC71AV1A	FTXC85AV1A	FTXC100AV1A
Outdoor Unit	RXC50AV1A	RXC60AV1A	RXC71AV1A	RXC85AV1A	RXC100AV1A
Cooling Capacity Rated/Min-Max (kW)	5.0 (1.4-6.0)	6.0 (1.4-7.1)	7.1 (3.2-8.0)	8.5 (4.0-10.0)	10.0 (5.0-11.2)
Heating Capacity Rated/Min-Max(kW)	6.0 (1.4-7.1)	7.1 (1.4-8.0)	8.0 (3.5-9.0)	10.0 (4.1-11.2)	11.2 (5.1-12.5)
Power Supply	1 Phase, 220-240V, 50Hz
Power Consumption (Cool/Heat) (kW)	1.45 / 1.61	1.80 / 2.05	2.22 / 2.37	2.59 / 3.01	3.11 / 3.48
EER / COP (kW/kW)	3.45 / 3.73	3.33 / 3.46	3.20 / 3.38	3.28 / 3.32	3.22 / 3.22
AEER / ACOP	3.33 / 3.61	3.24 / 3.38	3.13 / 3.31	3.22 / 3.27	3.16 / 3.17
TCSPF Cooling Commercial Hot/Avg/Cold	5.30 / 5.23 / 5.53	5.01 / 4.98 / 5.27	4.85 / 4.88 / 5.19	5.01 / 5.06 / 5.40	5.03 / 5.12 / 5.48
TCSPF Cooling Residential Hot/Avg/Cold	4.80 / 3.99 / 4.00	4.58 / 3.92 / 3.95	4.46 / 3.92 / 4.00	4.61 / 4.10 / 4.21	4.63 / 4.17 / 4.31
HSPF Heating Commercial Hot/Avg/Cold	5.39 / 4.96 / 4.50	5.16 / 4.71 / 4.22	4.47 / 4.16 / 3.79	4.49 / 4.17 / 3.77	4.66 / 4.25 / 3.77
HSPF Heating Residential Hot/Avg/Cold	5.36 / 4.64 / 4.14	5.13 / 4.38 / 3.84	4.46 / 3.94 / 3.52	4.48 / 3.93 / 3.49	4.64 / 3.95 / 3.42
Indoor Decoration Panel Colour	Fresh White
Indoor Airflow Rate (H/M/L) (l/s)	300 / 267 / 233			433 / 383 / 317
Indoor Sound Pressure Level (H/M/L) (dBA)	45 / 42 / 40			49 / 45 / 41
Indoor Sound Power Level (H/M/L) (dBA)	61 / 58 / 56			65 / 62 / 58
Outdoor Unit Colour	Ivory White
Compressor Type	Hermatically Sealed Swing Type
Compressor Motor Output (kW)	1.3		2.4	3.3
R32 Refrigerant Amount/Charge (kg)	0.73 (Charged for 10m)		1.50 (Charged for 10m)
Outdoor Sound Pressure Level Cool/Heat (dBA)	48 / 51		48 / 50	52 / 53	51 / 53
Outdoor Sound Pressure Level Night Quiet Mode (dBA)	44			48	47
Outdoor Sound Power Level (dBA)	68		67	71	70
Indoor Operating Range Cool/Heat (C)	14 to 25 / 15 to 27
Outdoor Operating Range Cool/Heat (C)	-5 to 50 / -15 to 15.5
Pipe Sizes (Liquid/Gas) (mm)	6.4 / 12.7		9.5 / 15.9
Max. Interunit Piping Length (m)	50 (Equivalent Length 70)		75 (Equivalent Length 90)
Max. Installation Height Difference (m)	30
Heat Insulation	Both Liquid and Gas Piping
Indoor Unit Dimensions (HxWxD) (mm)	290 x 1050 x 238			340 x 1200 x 240
Outdoor Unit Dimension (HxWxD) (mm)	595 x 845 x 300		990 x 940 x 320		1430 x 940 x 320
Indoor Unit Weight (kg)	13			17
Outdoor Unit Weight (kg)	45		69	78	93

SKU	FTXC50A-AV
Brand	Daikin
Shipping Weight	58.0000kg
Shipping Width	0.357m
Shipping Height	0.595m
Shipping Length	1.050m
Shipping Cubic	0.223304000m3
Unit Of Measure	ea
