Daikin SkyAir FAA85B-VC2Y 8.5kW Wall Split 3 Phase Air Conditioning System

Calculate Shipping

Request Separate Shipping Quote
Best suited for large or bulky orders. After receiving your order, our team will contact you to arrange a custom shipping quote based on current freight market rates to your location. We work with multiple freight providers to find the best pricing and delivery option for your needs. Please note that final shipping costs will vary from the online shipping estimate.

Pick Up- $0.00 (ETA: 1 days)
Pick Up from our Brisbane Warehouse. Mon - Fri 8am - 4pm. Please wait for pickup confirmation call or email. Or contact us prior to picking up to ensure your unit is packed and ready to go.

Pick Up- $0.00 (ETA: 1 days)
Pick Up from our Sydney Warehouse. Mon - Fri 8am - 4pm. Please wait for pickup confirmation call or email. Or contact us prior to picking up to ensure your unit is packed and ready to go.

System Names	FAA71B-VC2Y	FAA85B-VC2Y	FAA100B-VC2Y
Indoor Unit	FAA71BVMA	FAA85BVMA	FAA100BVMA
Outdoor Unit	RZAV71C2Y1	RZAV85C2Y1	RZAV100C2Y1
Cooling Capacity Rated/Min-Max (kW)	7.1 (3.2-8.0)	8.5 (4.0-10.0)	10.0 (5.0-11.2)
Heating Capacity Rated/Min-Max(kW)	8.0 (3.5-9.0)	10.0 (4.1-11.2)	11.2 (5.1-12.5)
Power Supply	3 Phase, 380-415V, 50Hz
Power Consumption (Cool/Heat) (kW)	2.22 / 2.37	2.59 / 3.01	3.11 / 3.48
EER / COP (kW/kW)	3.20 / 3.38	3.28 / 3.32	3.22 / 3.22
AEER / ACOP	3.13 / 3.31	3.22 / 3.27	3.16 / 3.17
TCSPF Cooling Commercial Hot/Avg/Cold	4.85 / 4.88 / 5.19	5.01 / 5.06 / 5.40	5.03 / 5.12 / 5.48
TCSPF Cooling Residential Hot/Avg/Cold	4.46 / 3.92 / 4.00	4.61 / 4.10 / 4.21	4.63 / 4.17 / 4.31
HSPF Heating Commercial Hot/Avg/Cold	4.47 / 4.16 / 3.79	4.49 / 4.17 / 3.77	4.66 / 4.25 / 3.77
HSPF Heating Residential Hot/Avg/Cold	4.46 / 3.94 / 3.52	4.48 / 3.93 / 3.49	4.64 / 3.95 / 3.42
Indoor Decoration Panel Colour	Fresh White
Indoor Airflow Rate (H/M/L) (l/s)	300 / 267 / 233	433 / 383 / 317
Indoor Sound Pressure Level (H/M/L) (dBA)	45 / 42 / 40	49 / 45 / 41
Outdoor Unit Colour	Ivory White
Compressor Type	Hermatically Sealed Swing Type
Compressor Motor Output (kW)	2.4	3.3
R32 Refrigerant Amount/Charge (kg)	2.60 (Charged for 30m)	2.90 (Charged for 30m)	3.75 (Charged for 30m)
Outdoor Sound Pressure Level Cool/Heat (dBA)	48 / 50	52 / 53	51 / 53
Outdoor Sound Pressure Level Night Quiet Mode (dBA)	44	48	47
Outdoor Sound Power Level (dBA)	67	71	70
Indoor Operating Range Cool/Heat (C)	14 to 25 / 15 to 27
Outdoor Operating Range Cool/Heat (C)	-5 to 50 / -15 to 15.5
Pipe Sizes (Liquid/Gas) (mm)	9.5 / 15.9
Max. Interunit Piping Length (m)	75 (Equivalent Length 90)
Max. Installation Height Difference (m)	30
Heat Insulation	Both Liquid and Gas Piping
Indoor Unit Dimensions (HxWxD) (mm)	290 x 1050 x 238	340 x 1200 x 240
Outdoor Unit Dimension (HxWxD) (mm)	990 x 940 x 320		1430 x 940 x 320
Indoor Unit Weight (kg)	13	17
Outdoor Unit Weight (kg)	69	78	93

(FAA85B-VC2Y)

System Names	FAA71B-VC2Y	FAA85B-VC2Y	FAA100B-VC2Y
Indoor Unit	FAA71BVMA	FAA85BVMA	FAA100BVMA
Outdoor Unit	RZAV71C2Y1	RZAV85C2Y1	RZAV100C2Y1
Cooling Capacity Rated/Min-Max (kW)	7.1 (3.2-8.0)	8.5 (4.0-10.0)	10.0 (5.0-11.2)
Heating Capacity Rated/Min-Max(kW)	8.0 (3.5-9.0)	10.0 (4.1-11.2)	11.2 (5.1-12.5)
Power Supply	3 Phase, 380-415V, 50Hz
Power Consumption (Cool/Heat) (kW)	2.22 / 2.37	2.59 / 3.01	3.11 / 3.48
EER / COP (kW/kW)	3.20 / 3.38	3.28 / 3.32	3.22 / 3.22
AEER / ACOP	3.13 / 3.31	3.22 / 3.27	3.16 / 3.17
TCSPF Cooling Commercial Hot/Avg/Cold	4.85 / 4.88 / 5.19	5.01 / 5.06 / 5.40	5.03 / 5.12 / 5.48
TCSPF Cooling Residential Hot/Avg/Cold	4.46 / 3.92 / 4.00	4.61 / 4.10 / 4.21	4.63 / 4.17 / 4.31
HSPF Heating Commercial Hot/Avg/Cold	4.47 / 4.16 / 3.79	4.49 / 4.17 / 3.77	4.66 / 4.25 / 3.77
HSPF Heating Residential Hot/Avg/Cold	4.46 / 3.94 / 3.52	4.48 / 3.93 / 3.49	4.64 / 3.95 / 3.42
Indoor Decoration Panel Colour	Fresh White
Indoor Airflow Rate (H/M/L) (l/s)	300 / 267 / 233	433 / 383 / 317
Indoor Sound Pressure Level (H/M/L) (dBA)	45 / 42 / 40	49 / 45 / 41
Outdoor Unit Colour	Ivory White
Compressor Type	Hermatically Sealed Swing Type
Compressor Motor Output (kW)	2.4	3.3
R32 Refrigerant Amount/Charge (kg)	2.60 (Charged for 30m)	2.90 (Charged for 30m)	3.75 (Charged for 30m)
Outdoor Sound Pressure Level Cool/Heat (dBA)	48 / 50	52 / 53	51 / 53
Outdoor Sound Pressure Level Night Quiet Mode (dBA)	44	48	47
Outdoor Sound Power Level (dBA)	67	71	70
Indoor Operating Range Cool/Heat (C)	14 to 25 / 15 to 27
Outdoor Operating Range Cool/Heat (C)	-5 to 50 / -15 to 15.5
Pipe Sizes (Liquid/Gas) (mm)	9.5 / 15.9
Max. Interunit Piping Length (m)	75 (Equivalent Length 90)
Max. Installation Height Difference (m)	30
Heat Insulation	Both Liquid and Gas Piping
Indoor Unit Dimensions (HxWxD) (mm)	290 x 1050 x 238	340 x 1200 x 240
Outdoor Unit Dimension (HxWxD) (mm)	990 x 940 x 320		1430 x 940 x 320
Indoor Unit Weight (kg)	13	17
Outdoor Unit Weight (kg)	69	78	93

SKU	FAA85B-VC2Y
Brand	Daikin
Shipping Weight	95.0000kg
Shipping Width	0.333m
Shipping Height	0.990m
Shipping Length	1.200m
Shipping Cubic	0.395712000m3
Unit Of Measure	ea
