Toshiba Super Digital RAV-SM1404UT-E / RAV-SP1404AT-A 11.2kW Cassette

Indoor Super Digital Cassette

$4,159.00
In Stock


Calculate Shipping



Pick Up - $0.00 (ETA: 1 days)
Pick Up from our Brisbane Warehouse. Mon - Fri 8am - 4pm.

The RAV-SM1404UT-E is Toshiba's 12.5W In-ceiling Cassette Unit. This Inverter System has a cooling capacity ranging from 2.6kW to 14.0kW and a heating capacity ranging from 2.4kW to 16.5kW.

(RAV-SM1404UT-E)

Indoor RAV-SM1404UT-E
Outdoor RAV-SP1404AT-A
Refrigerant Type   R410A
Power Suppply Volts / Phase / Hz 220-240 / 1 / 50
Cooling Capacity - Rated kW 12.5
Capacity - Range kW 2.6 - 14.0
Efficiency (Rated) EER 3.96
Power Input (min - rated - max) kW 0.64 - 3.16 - 4.40
Operating Current (rated) A 14.66
Heating Capacity - Rated kW 14.0
Capacity - Range (min - max) kW 2.4 - 16.5
Efficiency (rated) COP 4.36
Power Input (min - rated - max) kW 0.52 - 3.21 - 4.50
Operating Current (rated) A 14.89
Indoor Unit Dimensions (HxWxD) mm 319 x 840 x 840
Net Weight kg 24
Airflow Volume (H/L) L/s 583.5 - 341.7
Fan Motor Output W 72
Sound pressure (H/M/L) - 1m dBA 44 / 38 / 34
Sound Power (H/M/L) dBA 59 / 53 / 49
Outdoor Unit Dimensions (HxWxD) mm 1340 x 900 x 320
Net Weight kg 93
Compressor Type   DC Twin Rotary
Fan Motor Output W 100 + 100
Cooling Operating Noise (Sound Pressure) (H) - 1m dBA (@spl) 51
Cooling Operating Noise (Sound Power) (H) dBA (@swl) 68
Heating Operating Noise (Sound Pressure) (H) -1m dBA (@spl) 52
Heating Operating Noise (Sound Power) (H) dBA (@swl) 69
Cooling Usable Temperature Range °CDB -15 to 43
Heating Usable Temperature Range °CWB -20 to 15
Pipe Size Liquid Line Ø mm 9.5
Gas Line Ø mm 15.9
Coupler Style   Flaring
Drain (Inside Diameter) Ø mm VP25
Maximum ength m 75
Chargeless Length m 30
Maximum Height Difference m 30
SKU RAV-SM1404UT-E
Brand Toshiba
Shipping Weight 117.0000kg
Shipping Cubic 0.611006m3
